Robotic Cylinder Mower

An autonomous reel mower engineered for premium turf, delivering tournament-grade precision and consistent cutting quality. Equipped with RTK and LiDAR navigation, it operates accurately even in obstructed areas, enabling fully unmanned, efficient, and cost-effective turf maintenance for golf courses and sports fields.

PROFESSIONAL MOWING SOLUTION FOR GOLF COURSES

Precision Height · Tailored for Golf Course

Adjust cutting height freely from 7mm to 44mm, helping you get the grass just right for both fairways and roughs on golf courses.

Fleet Management

Distribute mapping to multiple mowers from the cloud platform and allow them to work together for maximum efficiency.

Floating Blade Design

Follow the ground' s shape automatically with a floating blade, making it easier to get a consistent cut and prevent turf scalping.

No Signal Loss Under Trees

Leverage RTK and LiDAR for high-precision navigation, with no signal loss even under trees or in signal-obstructed areas.

Specifications

  • Precision Cutting · Designed for Sports Field
    Reel cutting trims grass cleanly like scissors, minimizing tearing for healthier turf—built for the demands of sports fields.


  • Professional Grade Striping
    Create clean, high-contrast stripes with precision roller blades. You can customize striping widths to meet your field style.


  • Multi-Zone Management
    Mow multiple zones in one task and automatically move to the next one after completion, working non-stop without you having to do anything.

Upgraded User Experience: Safer, Smarter, More Efficient.

  • Fast Mapping
    With the V4e Mini RTK Receiver or P2 Scanner, you can create operation maps within minutes — no need to drive the machine into the field. Get started faster and safer.


  • Comprehensive Safety Protection
    Equipped with front and rear bumpers, radar obstacle avoidance, emergency stop button, remote stop via APP, and electronic fencing, multiple safety layers ensure stable and secure autonomous operation.


  • One-Stop Digital Control
    Using the dedicated APP, users can remotely control machines, schedule mowing plans, and monitor live or historical data. Integrated with the Greenmaster Platform, all task maps and machine data are managed in one place for streamlined digital operations.


  • Shape the Turf, Define the Look
    By changing the reel mowing angle, stripe width and direction can be freely controlled, creating neat, professional, and customizable turf patterns.


  • Do More with Less
    One supervisor can remotely manage multiple mowers, freeing labor for higher-value tasks.

Specifications

Fast battery swapping mode*

20000㎡

Cutting height

7 - 44 mm

Cutting width

68.6 cm / 27 in.

Travel speed

6 km/h

Max climbing ability

20°

Battery capacity

8 KWh

Battery life

10 h

Charging time

5 h

Operating temperature

-20℃-45℃

IP Rating

IPX4
